006.1 – Wire 500 mm long, 2mm thick

Basic info

• Wire
• Material: bendable/strong
• Measures: ~500mm long, 2mm thick

Tolerance

• Size: the length is within standard tolerance, the thickness should be 2mm as this comes with a certain strength required for the use cases of this part
• Material: standard tolerance but it should be strong enough to support the (most) use cases of this part.

Get this part

• Buy: this is an off the shelf part. You can get wire like this in many different forms in every hardware store – online and offline. Sometimes you can get some wires with nice plastic or rubber covering.
• Make: no instructions available. But here is a tip: get some 2mm wire and then some plastic or silicone tubes to cover it up nicely.

Introduced by

• Lars Zimmermann via “Welt am Draht”
• Original post, original post backup.pdf
• Open: “I bought this part off the shelf. It is most likely prior art but I don’t guarantee this.”
• Disclaimer
