099.2 – wheel with break, M6 thread

Part Info

• What is it: Off the shelf wheel, with a break
• Material: strong
• Measures: ~40mm (wheel ~25), M6 thread 15mm long

Tolerance

• Size: standard tolerance
• Material: standard tolerance

Get the part

• Buy: Available in several stores. Search for “wheel M6 thread”
• Make: No instructions available.

Introduced by

• Lars Zimmermann via “Europe is cool”
• Original post, original post backup (pdf)
• Open: I bought this off the shelf. It is a standard. You can probably get a version of this that is prior art.
