Basic info
- A disk
- material: strong
- measures: Outer ⌀ ~75mm, thickness ~16mm
- holes: Ikego grid, 5 holes ⌀ 6mm (for more info download vector files below)
Tolerance
- Size: standard tolerance – but you can’t go all the 15mm in because you’ll run into the holes of course
- Material: standard tolerance
Get this part
- Buy: Available as local make.
- Make: This is easy to make by hand. A laser cutter works well for all kinds of sheet material. → Download vector files here.
Introduced by
- Lars Zimmermann via Trikkka headphones
- Open: Shared under TPP 1.0
- Original post (7), original post backup pdf (7)
- Disclaimer
