Basic info
- What it is: Off the shelf M6 wing nut
- Material: strong | standard tolerance
- Dimensions: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “M6 wing nut”
- Make: No instructions available
Introduced by
- Lars Zimmermann and Max Cuppens via Addi One
- Original post, original post backup.pdf
- Open: Prior art (most likely)
- Disclaimer
