Meta
- What is it: a box
- Material: strong
- Measures: ~330x330x240mm, wall thickness ~16mm
- Holes: Ikego Grid, 4 holes on all 4 sides, ⌀ 10mm, for distance see drawing:
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get the part
- BUY
- Globally ↓
- Available as local make.
- From Max of Materialogic (made on demand, shipping from Germany)
- Locally ↓
- None so far
- Want to make and sell this part? Add your store
- Make: The images above show 3D printed versions of the box. Of course, you can build the box differently. But if you have a large 3d printer, you can print it yourself. Request or download the stl file here. The print file doesn’t include the holes. You will have to drill them manually. We recommend a wall thickness of at least 4mm to get a decent strong box.
Introduced by
- Designer: Max Cuppens via Vito 1-4
- Original post, Original post backup (pdf)
- Open: Shared under IPP 1.0.
