Basic Info
- What is it: a small sheet (“backpack handle”)
- Material: strong but bendable | standard tolerance
- Dimensions: see drawing or vector file | standard tolerance
- Holes: Ikego Grid ⌀10mm, for exact location download vector file
Get the part
- Buy: available as local make
- Make: You can cut it by hand or use a laser cutter (for example from 0,5 mm thick Polypropylen-Sheets. Download and use this lasercutter-ready SVG-file
Meta
- Introduced by: Lars Zimmermann / Mifactori via Mifactori Backpack
- Initial post, initial post backup.pdf
- Open: Shared under IPP 1.0
- Disclaimer
