019.1 – M4 nut

Basic info

• Off the shelf M4 nut
• material: strong

Tolerance

• Size: thread ISO/DIN 13. But if you have nuts and bolts from a different standard with a diameter of 4mm it should work in most applications.
• Material: standard tolerance

Get this part

• Buy: Readily available in stores, search for: “M4 nut”
• Make: No instructions available

Introduced by

• Lars Zimmermann via Flower Hanger
• Open: Prior art (most likely)
• Original post (13), original post backup pdf (13)
• Disclaimer
