088.2 – M6 sleeve nut ~16mm

Part Info

• What is it: M6 sleeve nut
• Material: strong
• Measures: ⌀ 10mm, height ~16mm

Tolerance

• Size: standard tolerance except the diameter which should be 10mm or less.
• Material: standard tolerance

Get the part

• Buy: Readily available in stores, search for: “M6 sleeve nut”
• Make: No instructions available.

Introduced by

• Lars Zimmermann, via Friend
• Original post, original post backup (pdf)
• Open: off the shelf part, probably prior art
