Basic info
- Off the shelf clockwork
- material: diverse
- measures: ~50x50x2mm, thread length ~16mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “clockwork”. This is a standard available across the globe.
- Make: No instructions available yet.
Introduced by
- Lars Zimmermann via Platform Clocks
- Original post, original post backup.pdf
- Open: This part was bought off the shelf. It is probably prior art. This kind of technology exists for a long time. But: We recommend to buy it off the shelf. If you attempt to make this yourself you should know what you do – engineering wise and also legally.
Download Portal
Most parts have open design and manufacturing files you can download and work with.
0P3N Portal
