Basic Info
- What is it: M4 Ringbolt ~40mm
- Material: strong
- Dimensions: ~40mm long, hole in ring at least ⌀ 4mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get the part
- Buy: available as local make plus readily available in stores, search for “M4 ringbolt 40mm”
- Make: no instructions available
Meta
- Introduced by: Lars Zimmermann via Climate Change Survival Fortune Angels
- Original post, original post backup.pdf
- Open: Off the shelf part. Most likely prior art, unless you get a very special version.
- Disclaimer
