Basic Info
- What is it: a cushion roll
- Material: soft | standard tolerance
- Dimensions: ~ 300mm long, diameter ~ 65mm | standard tolerance
- Holes: One center hole with a diameter of ~ 25mm
Get the part
- Buy: Available as local make
- Make: There are several easy/DIY friendly ways to make this part:
- PoolNoodles! Take a pool noodle and cut it to size. Some already have a hole in the center. If not you can drill it with a milling drill
- You can by in hardware stores foam covers that are supposed to go over piping (see picture with the grey foam). They come in different sizes. One of the sizes available in Germany fits perfectly!
- Hint: To make this more durable and more aesthetically appealing you might put a sewed cushion cover over the pillow. This would be an extra Ikego part, we did not add so far.
Meta
- Introduced by:Rinaldoo Boom via GROW | initial post | initial post backup.pdf
- Open: Shared under IPP 1.0
- Disclaimer: This part is just a concept and not fully tested. You should not assume that it works as indicated and I am not saying that it does. I disclaim any responsibility or liability for any damage caused during the construction and use of products based in whole or in part on the concept shown here. All information is provided for your use at your own risk.
