Basic info
- Off the shelf set screw
- material: strong
- measures: M3, ~16mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “M3 set screw”
- Make: No instructions available
Introduced by
- Lars Zimmermann via pen O-Pen
- Original post, original post backup.pdf
- Open: Prior art (most likely)
- Disclaimer
