Basic info
- Off the shelf M6 eye bolt
- material: strong
- measures: length ~ 40 mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “M6 eye bolt”.
- Make: No instructions available
Introduced by
- Lars Zimmermann via Addi One
- Original post, original post backup.pdf
- Open: Prior art (most likely)
- Disclaimer
