Basic Info
- What is it: a board
- Material: strong | standard tolerance
- Dimensions: ~360x150x18mm| standard tolerance
- Holes: Ikego Grid, 4 holes ⌀ 10mm, see drawing for location
Get the part
- Buy: available as local make
- Make: no instructions available
Meta
- Introduced by: Lars Zimmermann, via “NoTALKI”
- Original Post, Original Post Backup.pdf
- Open: Shared under IPP 1.0
- Disclaimer
