Basic info
- Off the shelf M6 bolt
- material: strong
- measures: ~ 110 mm long
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “M6 bolt 110”
- Make: No instructions available
Introduced by
- Designer: Lars Zimmermann via Bengi bench
- Original post, original post backup.pdf
- Open: Prior art (most likely)
- Disclaimer
