Set #026
Parts list
Parts appearing in this set
085.1 – Thread insert M10
084.1 – Threaded cap M10
069.1 – M4 washer 15mm
058.1 – Strap 90mm, 3 holes
057.1 – Set collar rail ⌀ 16mm hole
044.1 – M4 wing nut
042.1 – M4 knurled nut
026.1 – Branch
025.1 – M4 hook ~40mm
019.1 – M4 nut
013.1 – E14 bulb holder
010.1 – Cable with plug and switch
001.1 – Rod 390mm long ⌀ 16mm
Lift
MODEL+ This set has more than one model. Not all parts in the list are required to assemble each version.
ASSEMBLY+ There is more than one way to assemble this model. Some parts are interchangeable. Not every part in the list ist required for each way.
‘Lift Lamp‘ is a lamp that allows you to point the light bulb in any direction and that is not happy that the internet infrastructure is to a large extent controlled by only a few questionable corporations.
Status. Functional Prototype
Set info
Set No #026
On parts & builds
- Not shown in the pictures, but you can mount this to the table very easily, if your table has a hole.
Meta info
- Please visit the original post by the designer to find more pictures and information, building instructions and potentially updates about Addi and alternate builds of it. Initial post backup.pdf
- All makes shown in this post were created by Mifactori. → Add your make
- Pictures by Mifactori, CC-BY 4.0
