Basic info
- Off the shelf loop clip
- material: diverse
- measures: ~50mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “loop clip” or “loop clamp”.
- Make: No instructions available yet.
Introduced by
- Lars Zimmermann via Towli
- Original post, original ost backup.pdf
- Open: This part was bought off the shelf. It is probably prior art. For high volume commercial use though check the legal status though (and let us know please)
- Disclaimer
