083.1 – Rail 690mm

Basic info

• Rail
• material: strong
• measures: ~ 690 x 30 x 16 mm
• holes: 4 holes ⌀ 6mm in Ikego grid, see drawing for exact locations

Tolerance

• Size: standard tolerance (the lead image shows a pretty thick version of the part. But you can use much thinner material such as this for example.)
• Material: standard tolerance

Get the part

• BUY
• Globally ↓
  • Available as local make.
  • From Max of Materialogic (made on demand, shipping from Germany)
• Locally ↓
  • None so far
  • Want to make and sell this part? Add your store
• Make: no specific instructions available

Introduced by

• Designer: Lars Zimmermann via Bengi the bench
• Original post, original post backup.pdf
• Open: Shared under TPP 1.0
