Note: this is part 076.1 with one additional hole
- What is it: A rail
- Material: strong | standard tolerance
- Dimensions: ~ 600 x 30 x 16 mm | standard tolerance
- Holes: Ikego grid, 5 holes ⌀ 6mm, for hole distribution see drawing
Get the part
- Buy: available as local make
- Make: no instructions available
Meta
- Introduced by: Lars Zimmermann, via “Midlinging”
- Original Post, Original Post Backup.pdf
- Open: Shared under IPP 1.0
- Disclaimer
