Basic Info
- What is it: a board
- Material: strong | standard tolerance
- Dimensions: ~420mm x ~80mm x ~18mm | standard tolerance
- Holes: several holes, Ikego Grid, diameter 6mm, location see drawing
Get the part
- Buy: Available as local make
- Make: To drill the hole pattern correctly, you can 3D print a drilling template. Here is one for a board with a width of 80mm: DOWNLOAD STL.
Meta
- Introduced by: Arlie Lambright & Lars Zimmermann via Flappy World | Initial Post | Initial Post backup.pdf
- Open: Shared under IPP 1.0
- Disclaimer: This part is just a concept and not fully tested. You should not assume that it works as indicated and I am not saying that it does. I disclaim any responsibility or liability for any damage caused during the construction and use of products based in whole or in part on the concept shown here. All information is provided for your use at your own risk.
