Basic Info
- What is it: a beam
- Material: strong | standard tolerance
- Dimensions: length is fixed! to 240mm, but height ~80mm and thickness ~18mm are subject to standard tolerance
- Holes: Several, all in Ikego Grid. For location see drawing.
Get the part
- Buy: Available as local make
- Make: No instructions available
Meta
- Introduced by: Rinaldoo Boom via Bench 08 | initial post | initial post backup pdf
- Open: Shared under IPP 1.0
- Disclaimer: This part is just a concept and not fully tested. You should not assume that it works as indicated and I am not saying that it does. I disclaim any responsibility or liability for any damage caused during the construction and use of products based in whole or in part on the concept shown here. All information is provided for your use at your own risk.
