↓ Just super rough prototypes. A proper photo shoot of the final prototypes is still in the works. Stay tuned
‘Door Node‘ is a modular lever handle solution that combines elegant geometry with simple functionality.
By Max Cuppens, Lars Zimmermann
Status: Rough prototypes
Parts list
7 unique parts, in the →
Available to buy at
Globally available:
- as → professional local make. Order it from a local handyman. Learn more
Locally ⚑ available in:
- Sorry, no regional seller for this model yet. Sign up to our Newsletter to get notified when new sellers in your region are added. | Do you want to make and sell this? Add your store.
Design info
Set stats What does this mean?
- 3 prototypes
- 0 makes
- 0 products
Context info
- This was on of the first 10 sets created for the Ikego project.
On parts and builds
- This design probably looks and works best, when the Hub-Part (028.1) is transparent and the handle rod (001.2) is made from metal. But we have not tested other color combinations. Whatever materials you chose, a handle lever is under a lot of stress. Pick strong materials.
Meta info
- Please visit the original post by the designer to find even more information. Initial post backup pdf
- Disclaimer
Parts list …
Door Node
030.1 – M6 bolt ~30mm
029.1 – M6 round nut
028.1 – Doorknob node
027.1 – Rubber band ring ~150mm
001.2 – Rod 210mm, ⌀ 16mm
NOTE: This set has more than one model. Not all parts in the list are required to assemble each version.
NOTE: There is more than one way to assemble this model. Some parts are interchangeable. Not every part in the list ist required for each way.
