Basic info
- A rail
- material: strong
- measures: ~ 600 x 30 x 16 mm
- holes: Ikego grid, 4 holes ⌀ 6mm, for hole distribution see drawing
.
Tolerance
- Size: standard tolerance (the lead image shows a pretty thick version of the part. But you can use much thinner material such as this for example.)
- Material: standard tolerance
Get the part
- BUY
- Globally ↓
- Available as local make.
- From Max of Materialogic (made on demand, shipping from Germany)
- Locally ↓
- None so far
- Want to make and sell this part? Add your store
- Make: no specific instructions available
Introduced by
- Max Cuppens via Addi One
- Original post, original post backup.pdf
- Open: Shared under TPP 1.0
