079.1 – Beam 270mm

Basic info

• A beam
• material: strong
• measures:  270 x ~ 30 x ~ 30 mm
• holes: Ikego grid, 4 face-holes ⌀ 10mm, 2 side holes 6 mm. The side holes are drilled through the first face-hole so at least 50mm deep. For the exact location of the holes see also the drawing.

.

Tolerance

• Size: The length of this part is fixed to 270 mm and the distance of the holes to the side also. The thickness of the part is flexible within the standard tolerance
• Material: standard tolerance

Get this part

• BUY
• Globally ↓
  • Available as local make.
  • From Max of Materialogic (made on demand, shipping from Germany)
• Locally ↓
  • None so far
  • Want to make and sell this part? Add your store
• Make: No instructions available

Introduced by

• Lars Zimmermann via Addi One
• Original post, original post backup.pdf
• Open: Shared under TPP 1.0
