114.1 – 3 corner bracket, M6, 15mm to edge

What is it: A bracket with three sides
Material: strong | standard tolerance
Dimensions: ~22x22x22mm, the distance between the center of the hole and the edge is fixed to 15mm. All other dimensions are subject to the standard tolerance. All the brackets shown here (so far) create pockets for M6 nuts. This allows this part to be 3D printed for example and still have a strong thread and flush surface. However, angles without pockets are also part of this component if the other dimensions match. | STL files for various versions of this part are available for download below.
Holes: Three ⌀6mm

This distance (centre of hole to edge) is fixed on all three sides. All other dimensions are variable.

Closer shots of these versions, with a thin and thick version of the M6 nut (089.1)

Get the part

Buy globally:
- Available as local make.
Buy locally:
- None so far
- Want to make and sell this part? Add your store
Make: Birte shared .stl files for these brackets you can use to 3d print for example. Download STL link 1 (external folder) | link 2 (direct download)

Meta

Introduced by: Birte Hartmann via Tetri Box
Original post, Original post backup
Open: Shared under IPP 1.0
