Basic Info
- What is it: A magnet with a hole
- Material: magnetic | standard tolerance
- Dimensions: outer ø 9,4 mm, inner ø 6 mm. The outer diameter can vary, the inner diameter needs to be at least 6mm.
- Holes: one ⌀ 6mm
Get the part
- Globally
- This is an off the shelf part and probably easy to order from almost anywhere. Just search for it and buy.
- Available as local make.
- Locally ↓
- None so far
- Want to make and sell this part? Add your store
- Make: no instructions available
Meta
- Introduced by: Birte Hartmann via Tetri Box
- Original post, Original post backup
- Open: Off the shelf part. Probably prior art. But we can’t guarantee that.
- Disclaimer
Download Portal
Most parts have open design and manufacturing files you can download and work with.
0P3N portal
