005.2 – Disk 151,5 mm 13 holes

Basic info

• A disk with 13 holes
• material: strong
• measures: ⌀ 151,5mm, thickness ~16mm
• holes: 13 holes ⌀ 10mm. The distance between the neighbour holes in the outer ring follows the Ikego grid of 30mm.

Tolerance

• Size: The ⌀ of 151,5mm is important because the disk is supposed to fit tightly into the tube pieces 012.1, 015.1 and 048.1. The thickness is within the standard tolerance.
• Material: standard tolerance

Get this part

• BUY
• Globally ↓
  • Available as local make.
  • From Max of Materialogic (made on demand, shipping from Germany)
• Locally ↓
  • None so far
  • Want to make and sell this part? Add your store
• Make: You can make this with your hands or laser cut it. We’ll share laser cutter ready file for it. Download here (pls test the file before using it!)

Introduced by

• Lars Zimmermann & Max Cuppens via Platform Clocks
• Original post, original post backup.pdf
• Open: Shared under TPP 1.0
