Basic info
- Off the shelf M4 washer
- material: strong
- measures: ⌀ 15 mm
- holes: one center hole ⌀ 4,3 mm
Tolerance
- Size: standard tolerance
- Material: standard tolerance
Get this part
- Buy: Readily available in stores, search for: “M4 washer 15 mm”
- Make: No instructions available
Introduced by
- Lars Zimmermann via Lift Lamp
- Open: Prior art (most likely)
- Original post (20), original post backup pdf (20)
- Disclaimer
